The lab on an array (LOAA) dPCR approach separates the partitions on a two-dimensional semiconductor chip in a cartridge. The tube-strips are then read on a dedicated reader, which concurrently detects fluorescent signals from every partition of the digital PCR reactions. The partitions are sealed with a sealing fluid and the tubes are subjected to PCR in a conventional thermocycler. As dPCR mixture is added into each tube, the liquid is rapidly drawn into the partitions by capillary action. A miniature trapezoidal-shaped chip containing 10,000 partitions is found inside each tube. The dPCR system uses a strip of eight standard PCR tubes. This type of dPCR technology also combines a chip-based and droplet digital PCR approach. The droplet crystals undergo endpoint PCR, then they are transferred onto a fluorescent microscope and imaged to determine the number of amplified partitions. These droplets are called droplet crystals, because of the spontaneous periodic arrangement of the droplets within the monolayer, similarly to the that of atoms within crystals. The dPCR reaction mix is loaded onto a microfluidic chip, and placed in a dPCR system that partitions the sample into 2D monolayer arrays of monodisperse droplets. This hybrid dPCR approach combines the 2D array format of cdPCR and the use of droplet partitions in as in ddPCR. The chip undergoes endpoint PCR on a conventional thermal cycler and is analysed on a separate instrument. The plate is immersed in immiscible fluid (oil) to seal the sample on both sides and prevent evaporation or cross-contamination. The inner surfaces are coated with a hydrophilic surface, so samples can be loaded via capillary action. This dPCR technology encompasses an “open-array plate” consisting of 20,000 wells/partitions, etched through a microscope slide. Single DNA molecules are randomly distributed into nanoliter volume reaction chambers, prior to PCR amplification in the presence of a fluorophore-containing probe. The valves are used to regulate the flow of liquids in the array. The valves are made of an elastomeric material that deflects under pressure to create a tight seal. The microfluidic chamber array consists of a network of fluid lines, valves and chambers.
The copy number of the target sequence is calculated with accompanying software. Fluorescence is detected for all partitions on each chip using a high-powered camera reader equipped with a fluorescence filter. The chip is subjected to amplification with an endpoint PCR thermocycler. The dPCR reaction mix is divided into 10,000 to 45,000 partitions on a chip. Appearance of ddPCR rain droplets, which result from damaged droplets, non-specific amplification or irregular droplet size, makes setting of threshold that separates positive from negative droplets difficultįor more on dPCR vs ddPCR, such as limitations of ddPCR compared to nanoplate digital PCR, visit a dPCR information page or watch a webinar on plate-based dPCR vs ddPCR.Ĭhip-based digital PCR (cdPCR) involves the partitioning of a reaction into nanoliter reaction chambers by a microfluidic device.A typical ddPCR workflow requires multiple pipetting and transfer steps, which expose the ddPCR reactions to risk of cross-contamination and other errors.Data quality can be affected by coalescence or shearing of droplets caused by thermal oscillation.The ddPCR workflow is time-consuming and cumbersome.A droplet digital PCR system consists of multiple instruments (droplet generator, thermocycler, droplet reader) that take up valuable lap space and require trained personnel for operation.Droplet variability in size and shape adversely affect robustness and reproducibility of the method.Generates the largest number of partitions.
